What you’ll learn
Basics of Shaft design
Basics of Lay outing for power transmission systems
Shaft design for strength considering stress concentration and fatigue
Bearing Selection process and Bearing life calculations
How to calculate factors for modified L10 life of bearing
Gear design from scratch – specifications , CAD workflow, Force analysis and Stress analysis
Design methodology for Helical , Bevel and Worm gear design in Fusion 360
Description
Machine design is a large subset of study under mechanical eeering design which includes design of common components used in machines.
This is a mega-course of 3 courses in 1 which covers multiple aspects of design of Shafts and elements which are generally mounted it – Bearings and Gears.
It is a deep dive into the Shaft design process and selection also deals with the Bearing selection in detail . Then moving to a deep dive in Gear design with practical CAD design of gears based on input specifications.
Topics covered:
Shaft and layout design
Basics of simple power transmission system design
Loads and Load cases
Materials and manufacturing of shafts
Basics of Shaft design
Layout scheme and General lay outing
Keys and key ways
Set screws and collars
Splines and Serrations design selection based on standards
Interference and press fits
Stress analysis – method of analysis
Incorporation of stress concentration factors
Notch sensitivity in fatigue
Endurance limit and modifying factors
Deflection and Slope
Stress due to interference fits
Torque capacity of press fits
Solid vs Hollow shafts and Couplings
Bearing Selection
Factors which drive Bearing selection
Contact stresses study
Bearing life equation derivation and L10 life
Modified Life – Factors
Contamination factor, viscosity ratio
Deteing equivalent bearing load
Mounting scheme
Example to go through the selection process
Gear design
Conjugate action in Gears
