This is a full-length course on CATIA V5. This course will take you on a journey from nothing to a certified CATIA Designer. We have tried to make this course so comprehensive that you can get almost all demanding topics necessary in industries. This course includes all the tools that are required to create the basic and complex structures on the interfaces like Part Designs, Assembly Designs & Generative Sheet Metal Designs.——————————————————————-Why you should take this course?Firstly this course is made by the professional expert, who has more than 5 years of teaching experience and he knows how to make student understand every tools and topics.There are 120+ Lectures covering almost all the tools that is important for 3D Modelling in CATIA.This Course is made using CATIA V5 R19 version but you can able to work on any version of CATIA V5.We keep on upgrading this course according to the feedback of the students, and all the upgrades are always free once you enrolled.We have covered the DMU Kinematics Section in CATIA, with every details that you require for creating the simulation of the product.We have also included Video Examples for Assembly & Simulation of Various Product, Like Engine, CAM Follower, Shaper Mechanism. So that you understand the Assembly & Simulation clearly.We have also covered Generative Shape Design(Surfacing), which is the most important module in CATIA. We have also included Generative Sheet Metal Design that is one of the strong part of CATIA.We are always there to help you, just ask your doubts, we will clear them as soon as possible.Topics That We Cover In this Course.Sketcher: We will learn basic tools that are required for sketching your 2D Designs, We will learn about basic shapes, basic modification tools, and some advanced tools.Part Design: In this module, we learn to create 3D Models, we will going to spend a good time here learning all the tools used to create and modify models.Assembly Designs: Assembly is yet another important topic in which we will learn how to assemble parts and sub-assemblies to create a complete product. Here we will be going to use different constraints for our assemblies.DMU Kinematics: This is a very interesting module in which we will learn to simulate the product that we will create in an assembly, we will learn to create manual as well as automatic joints, there will be lots of examples as well that will help you to clear out your concepts.Sheet Metal: Sheet Metal is one of the most popular interfaces in CATIA, In this module, we will going to learn, how to create bends and cuts in the sheets and we will also going to different kinds of the stamping process.Generative Shape Designs(Surfacing): This is the most important module in CATIA. CATIA is widely used in locomotive industries for creating outer bodies of locomotives, that is majorly done in Generative Surface Design(Surfacing) Only.Drafting: In this, we will going to learn to produce our model into the drawing sheets with different views, like Standard Views, Section Views, etc. We are also going to see various annotations like Dimensions, text, etc., We will learn to create drawings of Parts, Assemblies, and Sheet Metals as well.Overview of What you will learn?Brief understanding of the interface of the CATIA Workbench.How to create sketches using different sketch tools.How to use constraints to define your sketch.How to create 3D Models with different Modelling tools like, PAD, Pocket, Shaft, Multi-section solid.How to create User Defined references, like Reference Plane, Points & Line.How to apply different materials and create rendering of the parts and product.How to use Different Pattern tools available in CATIA.We will cover some advance modelling tools, like Rib, Multi-Section with Guide Curve, etc.How to assemble the parts in Assembly design workbench.Some Important Assembly Features, like Multi-Installation, Define Multi Installation.After Assembly, we will simulate the product with DMU Kinematics Workbench.How to manually create simulation joints like, Revolute, Cylindrical, Planer Joints, etc.How to use “Assembly Constraints Conversion” tool for converting assembly joints into simulation joints.We will create sheet metal parts using “Generative sheet metal design interface”We will going to see tools like Flanges, Wall edge, Extrusion, Default Stamping tools.We will going to create user stamp as well and we will create dining plates and different exercises with that.Finally we end this course with Drafting, we create standard drafting using First & Third angle projections.We will see different view tools, like Section View, Projection View, etc.We will learn different annotations like dimensions, text, leader.We will also learn to create Assembly drafting and Sheet Metal Drafting.So, Overall it’s a complete course to learn CATIA. And Don’t worry about your doubts, we are always there to help you during this course, Just Ask!
